产品详情

NFC 抗金属标签

面议

产品详情

反金属射频识别标签是为在金属环境中的应用而设计的,允许RFID标签在金属上工作。

作为一个在这一行有10年时间的制造商,DTB可以为您提供不同形状和不同芯片的RFID标签。

库存产品可以免费提供样品。

请随时与我们联系。

材料:面纸:铜版纸或 PVC或PET

           吸波材料厚度(0.1mm, 0.2mm, 0.3mm, 0.35mm; 0.35mm)

           覆胶:3M胶

印刷:四色胶印, 丝印等.

尺寸:- 方形 --- 15*20mm, 40*25mm, 35*35mm, 48*48mm, 55*18mm 等.

           - 圆形 --- 直径-23mm, 直径-25mm, 直径-28mm, 直径-30mm, 直径-38mm, 直径-41mm, 直径-43mm etc.

           - 其他尺寸可客制.

工艺:编码, UID印刷, 一维码, 二维码等.

芯片

TypeChip modelUser Memory
Type 1Topaz 512512 bytes
Type 2MIFARE Ultralight ®64 bytes
MIFARE Ultralight ® EV1384/1024 bits
MIFARE Ultralight®  C192 bytes
NTAG213 / NTAG215 / NTAG216144/504/888 bytes
Type 4MIFARE ® DESFire ® EV1 (2K/4K/8K)2K/4K/8K bytes
Type 5ICODE® SLI-X1024 bits

Remark:
MIFARE and MIFARE Classic are trademarks of NXP B.V.
MIFARE DESFire are registered trademarks of NXP B.V. and are used under license.
MIFARE and MIFARE Plus are registered trademarks of NXP B.V. and are used under license.
MIFARE and MIFARE Ultralight are registered trademarks of NXP B.V. and are used under license.
